800W-2T Balcony Power Station
Technical Specifications
Recommended module power: up to 320W – 540+W (per module)
MPPT voltage range: 16–60 V
Start-up voltage: 22V
Maximum input voltage: 65V
Maximum input current: 2*14A
Maximum input short-circuit current: 2*25A
Rated output power: 800VA
Rated output current: 3.48A
Rated output voltage/range: 230V / 180-275V
CEC peak efficiency: 96.70%
Ambient temperature range: -40 to +65°C
Storage temperature range: -40°C to +85°C
Dimensions (WxHxD): 261 x 180 x 35.1 mm
Weight: 3.2 kg
Enclosure rating: IP67
Number of MPPTs: 2
This balcony power plant offers a high-performance solution with a total output of 940W, allowing you to generate part of your household’s electricity needs yourself. This can significantly reduce the costs of your total electricity consumption. The system consists of two high-quality Trina Solar solar modules, each with an output of 470W, featuring state-of-the-art technology. To boost efficiency, the set includes an HMS-800W-2T microinverter from Hoymiles. The kit also includes a 10-meter Hoymiles connection cable with a field connector for easy installation.
