100W (1190*450*30mm,19.28V) Frame Solar panel
90,00€
Nominal Power 100W
Maximum Power Current 5.19A
Maximum Power Voltage 19.28V
Open-circuit Voltage 22.92V
Short-circuit Current 5.50A
Maximum System Voltage 500V
Output Tolerance 0~+3%
Cable （MC4） 700mm / 2.5mm²
Module Structure Aluminum Frame / Glass / EVA /Backsheet
Junction box rating ≥IP67
Cell 210*33.2–34*2
Working Temperature -40~+80℃
Module Dimensions 1160*450*30mm
Weight（Net /Gross） 5.75/6.5kg
Διαθέσιμο
The efficiency of high-quality and high-efficiency monocrystalline silicon wafers can reach 22%. Using tempered glass, high transparency.
Anti-corrosion EVA effectively protects the battery panel.
Strong and anti-wind and snow, unique technology to avoid freezing of water in the frame and deformation.
Lightweight and flexible features can make it seamlessly integrated into your vehicle.
Packed in a single carton, with protective corners on all four corners.
Prevent the loss of electricity:used on the roofthe car, charge the car battery at anytime. Can prevent the car battery from losing electricity, and solve the situation that the car cannot be fired due to the battery loss caused by the long-term parking of the vehicle.
On-board electrical appliances: when using on-board electrical appliances, the original power of the car battery will not lose (car audio, navigator,driving recorder, exhaust fan, car blower, car refrigerator, cell phone, etc.
