Batterie Lithium 200Ah 12V LiFePO4 sous le siège-Bluetooth-BMS -Heater-Ultimatron
– 5 year warranty
– Prismatic class A battery cell
– Application available on Apple Store and Google Play
– Dimensions (L x W x H) mm: 357 * 338 * 152 mm
– Specially adapted to fit under the seat of a Fiat Ducato, Citroën, Peugeot motorhome
Nominal voltage 12.8 V
Nominal capacity 200 Ah
Capacity @ 36A 300 min
Energy 2560Wh
Resistance ≤15 mΩ @ 50% SOC
Self-discharge <3% / Month
Number of cycles >6000@80% DoD
Recommended charging current 60 A
Maximum charging current 100 A
Recommended charging voltage 14.6 V
Charge cut-off voltage 14.6 V (2000 ms)
Reconnection voltage ≤13.8 V
Equilibrium voltage >12.8 V
Maximum continuous discharge current 150 A
Peak discharge cut-off current 450A (200~500ms)
Discharge cut-off voltage 10 V (2000 ms)
Reconnection voltage >11.2 V
Short circuit protection 1000-2000A ±400A
（200~800μs）
Discharge temperature -20 ~ 75 ºC
Charging temperature 0 ~ 50 ºC
Heating operating temperature -35 ~ 5 ºC
Storage temperature -5 ~ 35 ºC
Weight 23.30 kg
Connection screw M8
Torque terminals 80 ~ 100 in-lbs (9 ~ 11 Nm)
Material Box Metal
International Protection Code IP62
Bluetooth Bluetooth 4.0 with smartphone app
Heating film 80W
Certifications CE
UN38.3
UL1642 & IEC62133
ECE R10
Shipping Classification UN 3480, CLASS 9
