SolaX ESS-TRENE 100kW / 215kWh C&I energy storage system with air cooling
AC input and output (grid-connected)
Nominal output power: 100 kW
Nominal output current: 144.4 A
Max. apparent output power: 110 kVA
AC rated voltage: 3/N/PE, 220/380 V, 3/N/PE, 230/400 V
Max. AC input apparent power: 110 kVA
Max. AC input current: 160 A
AC rated frequency: 50/60 Hz
Battery (HR140)
Battery type: LFP
Battery voltage range: 600-876 V
Max. charging/discharging current 160 A
General
Operating temperature range: -30°C to +55°C
Protection class: IP66
Cooling concept: Intelligent cooling
Communication: RS845, CAN, Ethernet, Dl
Weight: 85 kg
Dimensions: 665 x 950 x 310 mm
TRENE-P100B215 (complete cabinet)
AC input and output (mains connected)
Rated output power: 100 kW
Rated output current: 144.4 A
Max. apparent output power: 110 kVA
AC rated voltage: 3/N/PE, 220/380 V, 3/N/PE, 230/400 V
AC rated frequency: 50/60 Hz
Battery (HR140)
Battery type: LFP
Total battery capacity: 215 kWh
Battery nominal voltage: 768 V
Battery voltage range: 636-876 V
Max. charging/discharging current 140 A
General
Operating temperature range: -30°C to +55°C
Protection class: IP55
Cooling concept: Intelligent cooling
Fire protection: Aerosol (optional: Novec1230) / water
Weight: 2800 kg
Dimensions: 1680 x 2420 x 1200 mm
HR140 (battery)
Battery type: LFP
Single module: 14.3 kWh
Nominal voltage of a battery: 51.2 V
Battery voltage range: 40-58.4 V
Operating temperature range: -20°C to +53°C
Protection class: IP20
Communication with PCS: CAN
Weight: 115 kg
Dimensions: 461 x 228 x 778 mm
Scope of delivery
1x SolaX ESS-TRENE 100kW / 215kWh energy storage system with air cooling
1x Cover
4x Angle bracket
Includes installation and mounting accessories
The air-cooled energy storage system (ESS) from SolaX (MPN: 1070010119) delivers up to 100 kW of output power with 215 kWh of storage capacity and is designed for space-critical installations. It combines an energy conversion module with an intelligent, air-cooled LiFePO4 battery system. The existing EMS (Energy Management System) precisely controls charging and discharging so that the system stores and releases electricity as needed. Thanks to its modular architecture, you can scale the system to meet your needs, up to the megawatt hour range. The cabinet integrates seamlessly into grid-connected, off-grid, and hybrid applications.
It networks proprietary core components such as BMS (Battery Management System), EMS (Energy Management System), and PCS (Power Conversion System) for seamless integration, safe operation, and quick commissioningthe system records operating parameters as well as event and error logs seamlessly over 12 months, creating transparency for analysis, optimization, and verification. To do this, you can use the user-friendly SolaXCloud, where you can also create an intelligent schedule. The unbalanced three-phase output also ensures a stable supply with unevenly distributed loads. The result: flexible deployment planning, compact design, and reliably optimized energy storage
